Mitsubishi 1.7 Ton 2 Star MSY-JP22VF

Capacity (Tr) 1.7 Tr

Star Rating - As Per BEE 2 Star

Type (Cooling)
Indoor Unit
MSY-JP22VF
Outdoor Unit
MUY-JP22VF

Performance Parameters
Star Rating - As Per BEE 2 Star Bee rating
Power Supply 230 V / 50 Hz / Single Phase
Capacity (Rated Min-Max) 6.0(1.4-6.2)kW
Total Input (Rated Min-Max) 1.95(0.32-2.20)kW
ISEER 3.72
Operating Current (A) 8.7
Air Volume (CFM) Indoor Unit(Silent-Low-Mid-Hi-SHi) 253/334/417/536/671

Compressor, Refrigerant & Ambient Operations
SPL Indoor Unit(Silent-Low-Mid-Hi-SHi) dB(A) 29/37/41/45/51
Refrigerant R32 R32

Dimensions & Weight
Indoor unit Dimensions (H x W x D) mm 305x923x250
Weight kg 12.5
Outdoor unit Dimensions (H x W x D) mm 550x800x285
Weight kg 31.5
Breaker Size (MCB required) A 16
Ext.Piping Diameter Liquid mm (inches) 6.35(1/4)
Diameter Gas mm (inches) 12.7(1/2)
Max.Length Out-In m 20
Max.Height Out-In m 12
